5
MODIFICATIONS
MIC PRE/POST VCA: Internal jumpers are provided to assign Mic/Line Input signal to the Main Output pre or post VCA (Main Level).
From the factory, Mic/Line Input signal is assigned pre-VCA (affected by Main Level). To assign Mic/Line Input signal post-VCA (not
affected by Main Level), move jumpers P10 & P11 (‘L’ & ‘R’) backward one pin to the ‘POST’ position, using needle-nose pliers. These
jumpers are totally independent of each other. Therefore, Mic/Line Input signal may be assigned pre or post VCA for left & right Main
Outputs independently.. However, this assignment is usually the same for both left & right Main Outputs. CAUTION: When assigned
Post-VCA, Mic/Line Input signal can trigger, but will not be affected by
, the internal limiter circuit. Mic/Line Input signal cannot be assigned
Post-VCA unless
it is also assigned Post-Tone.
POST
R
PRE
POST
L
PRE
P10
P11
MICROPHONE POST TONE CONFIG JUMPERS (P10,P11):
CONFIGURE THESE JUMPERS FOR LEFT AND RIGHT
OUTPUTS WHENEVER MIC IS SELECTED POST-TONE.
OPTIONS ARE POST AND PRE OUTPUT LEVEL CONTROL
