• Air vent screw
Step 6 System Venting
Fill the System and vent the air from the heat exchanger using the air vent screw. Close
the vent screw ensuring that there are no leaks.
Note: You may need to balance the central heating system if the plinth heater is installed on the same circuit
as panel radiators.
Step 7 Fitting
Ensuring that the flexible hoses do not kink and the electrical cable is not in contact with any
hot surfaces slide the plinth heater under the cupboard until the front edge is just behind the
line of the plinth.
Replace the plinth and pull the heater through the opening till the front edge projects 8mm
through the plinth.
8mm
3
