# Endstops
endstops_enable true
# the endstop module is enabled by default and can be disabled
here
#corexy_homing false
# set to true if homing on a hbit or corexy
alpha_min_endstop 1.18v!
# add a ! to invert if endstop is NO connected to ground
alpha_max_endstop 1.19v!
# NOTE set to nc if this is not installed
alpha_homing_direction home_to_min
# or set to home_to_max and set alpha_max
alpha_min 0
# this gets loaded after homing when home_to_min is set
alpha_max 1065
# this gets loaded after homing when home_to_max is set
beta_min_endstop 1.20v!
#
beta_max_endstop 1.21v!
#
beta_homing_direction home_to_min
#
beta_min 0
#
beta_max 1070
#
gamma_min_endstop 1.22v!
#
gamma_max_endstop 1.23v!
#
gamma_homing_direction home_to_min
#
gamma_min 0
#
gamma_max 1000
#
# optional order in which axis will home, default is they all
home at the same time,
# if this is set it will force each axis to home one at a time
in the specified order
homing_order XYZ
# x axis followed by y then z last
# optional enable limit switches, actions will stop if any
enabled limit switch is triggered
alpha_limit_enable true #
set to true to enable X min and max limit switches
beta_limit_enable true #
set to true to enable Y min and max limit switches
gamma_limit_enable true #
set to true to enable Z min and max limit switches
alpha_fast_homing_rate_mm_s 50
# feedrates in mm/second
beta_fast_homing_rate_mm_s 50
# "
gamma_fast_homing_rate_mm_s 4
# "
alpha_slow_homing_rate_mm_s 25
# "
beta_slow_homing_rate_mm_s 25
# "
gamma_slow_homing_rate_mm_s 2
# "
alpha_homing_retract_mm 5
# distance in mm
beta_homing_retract_mm 5
# "
gamma_homing_retract_mm 5
# "
#endstop_debounce_count 100
# uncomment if you get noise on your endstops, default is 100
