Bilanciai D70 - Unpacking and Installation Guide; Terminal Unpacking; Connection Guide

1. Unpacking and Installation
*
Not included
**
Consult the user manual for instructions about how to connect the 12V external battery
*
*
Remove the terminal from
the pack along with the CD
containing the instructions.
Connect:
A. 12V** electric power
supply
B. any peripheral equipment
used (e.g.: printer)
C. weighing platform
D. D70A - Internal batteries
D70B - Mains power
socket
Press to power the
terminal.
85-265 V
ac
50/60 Hz
A
B
C
D
ON/OFF
A B B C
D
A B B C
D
D70A
D70B
