8
OUTLET INSTALLATION
1. Insert the liner assembly into the tank. For a lid unit, rotating the liner assembly may help get the liner
into the rectangular opening. If the recycle trough is too long to drop the unit directly into the opening,
you can remove the recycle trough by removing the screws holding it to airlift, then reattach it once
the liner is in the tank.
2. For a foot unit, put the liner assembly into the tank, making sure that the holes line up between tank
outlet and liner outlet.
3. Insert effluent line (4” schedule 40 PVC pipe, not provided) through tank into liner gasket until it hits
the baffle plate. Use a gasket, grout, mortar, or bituminous sealant (mastic) in the tank effluent hole
for a water-tight seal between hole and effluent pipe.
