BIO-MICROBICS MicroFAST 0.75 - Small Control Board Layout Diagrams

18
Enclosure
Type
Dimensions
Height, Width, Depth
Voltage Phase
Frequency
Hz
Amperage
Hinged
9 x 9¾ x 5 ¼ in [22.9 x 24.8 x 13.3 cm]
110VAC
1
60
10 A
Hinged
9 x 9¾ x 5 ¼ in [22.9 x 24.8 x 13.3 cm]
220VAC
1
60
10 A
SMALL CONTROL BOARD LAYOUT
110V
220V
SMALL CONTROL ENCLOSURE
