Catch plate
Place the plate and guides over each mounting hole.
Insert the mounting bolts through the plate and
mounting holes.
5
1. Slide this product onto the catch plate
centering the unit with the guide arrows on the Base.
2. You will hear a click once this product is securely
mounted to the catch plate.
3. This product will feel a little loose on the toilet bowl.
Adjust the fit from front to back and side to side for balance.
4. Tighten the nuts on both bolts securely.
7
Check for any water leaks.
※ Customers should use the new hose set provided
with the product. Do not use used set again.
8
Slide cone packing and washers onto the bolts
then fasten to securely mount bidet seat to toilet.
6
Installation Catch Plate.
Bolt and Nut Assembly.
Assembly. Connect the flexible tube from side of
T-Valve to this product,
Open the Angle Stop valve to fill water.
Cone Packing
Nut
Bolt Case
Bolt
Central mounting
groove
Bolt
BACK
L-Valve
171102_BB-1700,2000 USER's MANUAL.indd 19 2017-11-03 오전 11:28:12
