10. Specifications and Certifications
Dimensions:
Base: 26" w x 37" depth x 8.5" h (66 x 94 x 21.5 cm)
Platform: 21.5" diameter (55 cm)
Product Weight: 235 lb (106.5 kg)
All-In-One Flat Panel Display: 15.6" Color Touchscreen, Windows Operating System,
Ethernet, USB, Video/Audio Out, Built-In Speakers and Color Printer. Bolsters connectivity
options to other devices, enabling remote operation for data transfer and software
upgrades.
Display Height: Adjustable from 55” to 68.5" h (139.7 to 174 cm) from center of display
to floor, and 46” to 60” (117 152 cm) from center of display to platform.
Stability Levels: 12 dynamic levels, plus locked for static measurements
Platform Tilt: 20° from horizontal in all directions
Support Handles: Adjustable from 26" to 36" above platform (66 to 91 cm). Handles
can be removed from the system when not in use or interchanged with the optional
FreeSway Handles.
User Weight Capacity: Maximum: 400 lb (181 kg) Minimum: 60 lb (27 kg)
Printer: HP DeskJet
Printer Stand: 24" x 24" (61 x 61 cm)
Power: 115 VAC, 50/60 Hz, 15 amp line or 230 VAC, 50/60 Hz, 15 amp line
Power Rating: 520 watts
Certification: Certification: ETL listed to UL 60601-1 and CAN/CSA C22.2 No.:601-1-
M90. CE conformity to EN 60601-1, EMC compliance to EN 60601-1-2.
Step Stool
Dimensions: 19.75” w x 13.5” depth x 4.5” h (50 x 34 x 11 cm)
Total Shipping Weight: 15 lb (7 kg)
VibroTactile
Belt Dimensions:
Small/Medium: 28"-36” (71-91 cm)
Large/Extra Large: 36"-48” (91-122 cm)
LinkBox Transmitter Voltage: 5v DC
Current: 50 mA
Auxiliary Ports: RS-232, USB
Tactile Belt Receiver Box Voltage: 5v DC
Current: 260 mA (when charging)
Auxiliary Ports: USB (wired); LR-WPAN (wireless)
US Patent for FreeSway Handles
US 9,415,287 B2
