2-2 ECHO/VASC PRO VASCULAR ULTRASOUND TABLE
• For Reverse Trendelenburg positioning: press and hold down the head-end up button on the
hand-held controller. This will simultaneously lower the foot end and raise the head end of the
table. Release the button when desired angle is achieved.
Fowler Back Adjustment
The motorized Fowler back is infinitely adjustable to 80° via the hand-held or optional foot
controller.
Leveling The Table
The table has a self-leveling feature which can be used when the table is in a Trendelenburg or
Reverse Trendelenburg position.
• To level the table, press and hold both Fowler back buttons on the hand-held control.
Adjustable Sonographer Cutout Cushion
To assure both patient and sonographer comfort, the adjustable sonographer cutout cushion
can be fully lowered, or raised to either of two positions.
• To fully lower the cushion, reach under the cushion and squeeze together the two
sonographer cutout cushion release handles. This will release the cushion, which can now be
lowered. To return the cushion back to the level position, squeeze the handles together an
d
lift up on the cushion until it is higher than level and then lower the cushion back down until it
locks in the level position.
• To raise the cushion, lift up on the cushion. There are two positions in which the raised
cushion can be set. To set the cushion in the first raised position, lift the cushion two-thirds of
the way to vertical and then allow it to slide back down slightly until you feel it lock into
position. To raise the cushion to the fully raised position, lift the cushion all the way up to
vertical and then allow it to move back slightly until it locks into place. To lower the cushion
from either raised position lift up on the sonographer cutout cushion release lever (locate
d
along the head-end of the cushion) and then lower the cushion.
Cardiac Scanning Cutout
The cardiac drop-down cushion can be released by pressing the yellow release handle which can
be found toward the lower end of the Fowler back section on each side of the table.
The cushion can be returned from either side of the table. From the right side you will find a
handle located toward the head end of the table. By pressing this handle down, the cardiac
cushion will return to level. From the left side of the table, simply push the cushion back up to
level.
