BIODEX MEDICAL SYSTEMS, INC. © 2015 A-1
Appendix A - Specifications
Dimensions: 73" l x 30" w (185.4 x 76.2 cm); 35" w (88.9 cm) with optional side rails
Height Adjustable: 23" to 39" (58.4 to 99 cm)
Tabletop: Two primary sections: torso section features sonographer and patient cutouts with
Fowler positioning; lower body section remains fixed
Cardiac Scanning Cutout: 15.75″ l x 9.5″ w (40 x 24.1 cm) drop-down cushion releases from
either side of the table
Sonographer Cutout: 8" w x 14.75" l (20.3 x 37.4 cm) adjustable sonographer cushion
drops down or folds up for maximum access to the patient.
Mattress: Torso section 2" (5 cm) thick, lower body section 3" (7.6 cm) thick; foam rubber pad
covered with seamless, durable Naugahyde
®
Upholstery Color: Graphite
Motions:
Height Adjustable: 23" to 39" (58.4 to 99 cm)
Trendelenburg: 0° to 15°
Reverse Trendelenburg
:
0° to 30°
Fowler Back: 0° to 80° infinitely adjustable
Controls:
Hand Control: Activates height, Trendelenburg motions, F
owler positioning and auto level
motions
Foot Control (optional): Activates height, Trendelenburg motions, and Fowler positioning
Wheels: 5" (12.7 cm) individual locking swivel casters; central floor locking system
Patient Restraints: Two body straps
Finish: Powder coat
Patient Capacity: 500 lb (227 kg); Weight tested to four times the patient load rating
Weight: 335 lb (152 kg)
Power: 115 vac or 230 vac
Warranty: Two years parts and labor
Certifications: ETL and CETL listed to UL60601-1and CAN/CSA C22.2 No. 601.1-M90 and
EN60601-1 standards
Authorized European Community Representative:
EC REP
Emergo Europe
Molenstraat 15
2513 BH, The Hague
The Netherlands
MADE IN
U. S. A.
