BionX D-Series - P-Series Motor; Brake Switch; Power Supply; 37 V Single LED Battery Charger

11
3
250, 250HT, 350HT, or 500HS* P-Series Motor
• DC rear hub motor
• 250: nom. output 200 (AU & UK) or 250 watt –
nom. 7Nm / max. 25Nm (5.2/18.4 lb-ft) torque
• 250HT / 350HT: nom. output 200 (AU & UK),
250 (EU), 350 (NA) watts – nom. 9Nm / max. 40Nm
(6.6/29.5lb-ft) torque
• 500: nom. 500 watt – nom. 9Nm / max. 25Nm
(6.6/18.4lb-ft) torque
• Weight - 4.7kg (10.4lb)
• Brushless, gearless, with integrated torque sensor
• Generate mode for energy recuperation
• 8, 9, and 10 speed cassette compatible (EU only,
where available)
4
Brake switch
• A surface mounted reed switch and magnet –
connected to the BionX console
• Upon brake application assistance is shut off
(“kill switch”) and Generate mode is activated
Power Supply
• Power supply to recharge the 48V Li-Ion battery
• Input voltage: 100-240V
• Output voltage: 26V
• Max. charge current: 3.45A
• Output: 90W
37V Single LED Battery Charger
(PL systems 2011 to present)
• To recharge the 37V Li-Ion battery
• Input voltage: 100-240V
• Output voltage: 37V
• Max. charge current: 2A
• Output : 75 watts
22V, 26V or 37V Two LED Battery Charger
(PL systems 2011 and earlier)
• To recharge the 22V, 26V or 37V Li-Ion battery
• Input voltage: switchable between 115-230V
• Output voltage: 22V, 26V or 37V depending
upon model
• Max. charge current: 2A
*Note: the 500 watt motor is not legal in all jurisdictions. Check with your local BionX dealer for local legislation and/or availability.
