Brake switch
• A surface mounted reed switch and magnet –
connected to the BionX console
• Upon brake application, assistance is shut off
(“kill switch”) and Generate mode is activated
Power Supply
• Power supply to recharge the 48V Li-Ion battery
• Input voltage: 100-240V
• Output voltage: 26V
• Max. charge current: 3.45A
• Output: 90W
