9
3
S-Series Motor
• DC rear, high torque (HT) hub motor
• Power – (nom.) 200W (AU & UK), 250W (EU), 350W
(NA)
• Torque – (nom./max.) 9Nm/40Nm (6.6/29lb-ft)
• Weight – 3.5kg (7.7lb)
• Brushless, gearless
• Generate mode for energy recuperation
• Integrated torque sensor
• 8, 9, and 10 speed cassette compatible (NA only,
where available)
4
Brake switch
• A surface mounted reed switch and magnet –
connected to the BionX console
• Upon brake application, assistance is shut off
(“kill switch”) and Generate mode is activated
Power Supply
• Power supply to recharge the 48V Li-Ion battery
• Input voltage: 100-240V
• Output voltage: 26V
• Max. charge current: 3.45A
• Output: 90W
