BionX Smart - Installing the Rear Wheel

RL39 - Repair instructions for changing the frame
Version 1.0, last revised 03/2016
40/58
164.
Install the cable outlets on the right side of the downtube and on the right
rear stay. Tighten the bolt with a T25 Torx wrench and a torque of 2 Nm.
165.
Install the cable outlets on the left and right sides of the downtube. Tighten
the bolt with a T25 Torx wrench and a torque of 2 Nm.
166.
Install the cable duct on the left dropout.
KK. Installing the rear wheel
167.
Remove the transport lock from the rear brake caliper.
Hang the belt behind the mounting of the belt guide while you are inserting
the rear wheel into the dropouts. This will prevent you from trapping the belt
accidentally.
