RL39 - Repair instructions for changing the frame
Version 1.0, last revised 03/2016
7/58
Carefully press the belt off the rear belt pulley first, and then off the front belt
pulley.
Alternatively, push the lower span of the belt carefully towards the ebike so that it runs off the front belt pulley
when the crank is turned backwards.
Always observe the notes on handling the belt at the beginning of this repair guide.
In the next step, hold onto the rear wheel firmly so that it does not accidentally fall out of the frame.
Undo the nuts on the rear wheel axle using a size 15 open end wrench. The rear
wheel can now be removed downwards from the dropouts.
Push the transport lock between the brake pads.
