Biostar A770E3

A770E3 BIOS Manual
24
PCI Express Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Config uration
GPP Slots Power Li mit, W [25 ]
> Port #02 Feature s
> Port #04 Feature s
> Port #05 Feature s
> Port #06 Feature s
> Port #07 Feature s
> NB-SB Port Featu res
Peer-to-Peer among GFX/GFX2 [Disabled]
Options
Enabled
Disabled
Peer-to-Peer among GFX/GFX2
Options: Disabled (Default) / Enabled
GPP Slots Power Limit, W
Options: 25 (Default) / 0-255
Port #02/04/05/06/07 Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mo de [Auto]
Link ASPM [Disabled]
Link Width [Auto]
Slot Power Limit,W [75 ]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Auto (Default) / Disabled / Software Initiated / Advertised RC
