1.3 MOTHERBOARD FEATURES
SPEC
CPU
Socket AM3
AMD Sempron / Athlon II / Phenom II
processors (Maximum Watt: 95W)
AMD 64 Architecture enables 32 and 64 bit
computing
Supports Hyper Transport 3.0
FSB
Support HyperTransport 3.0
Supports up to 5.2 GT/s Bandwidth
Chipset
Northbridge: AMD 770
Southbridge: AMD SB710
Super I/O
ITE 8721
Provides the most commonly used legacy
Super I/O functionality
Low Pin Count Interface
Environment Control init iatives
H/W Mon itor
ITE's "Smart Guard ian" funct ion
Main
Memory
DDR3 DIMM Slots x 2
Max Memory Capacity 8GB
Each DIMM supports 512MB/
1GB/2GB/4GB DDR3
Dual Channel Mode DDR3 memory module
Supports DDR3 800 / 1066 / 1333
Supports DDR3 1600 (OC)
Registered DIMM and ECC D IMM is not supported
IDE Integrated IDE Contro ller
Multi-word DMA, and Ultra DMA 33/66/100/133
modes
SATA II Integrated Serial ATA Controller
Data transfer rates up to 3 Gb/s
SATA Version 2.5 s pecif icat ion co mp liant
LAN Realtek RTL 8102EL
10 / 100 Mb/s auto negotiation
Half / Full duplex capability
Sound ALC662 / VT1708B
5.1 channels audio out
High Definition Audio
Slots
PCI Express Gen2 x16 slot x1
PCI Express Gen2 x1 slot x1
PCI slot x3
Supports PCI-E Gen2 x16 expansion card
Supports PCI-E Gen2 x1 expansion card
Supports PCI expansion cards
Floppy Connector x1 Each connector supports 1 Floppy drive
IDE Connector x1 Each connector supports 2 IDE device
SATA Connector x4 Each connector supports 1 SATA devices
Front Panel Connector x1 Supports front panel facilities
On Board
Connector
Front Audio Connector x1 Supports front panel audio function
