Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
USBKBMS1
HDMI1
VGA1
DVI1
RJ45USB1
AUDIO1
JUSBV1
JU SBV3
LAN
Codec
Super I/O
F_AUDIO1
JSPDIFOUT1
CIR1 J_PRINT1 J_COM1 F_USB1
JUSBV2
F_USB2
SYS_FAN1
PANEL1
SATA1
SATA2
BIOS
SATA3
SATA4
JCMOS1
BAT1
ATXPWR1
D3_1DR A
D3_1
DR B
CPU_FAN1
PCI1
PCI2
PEX16_1
AMD
880G
AMD
SB850
Socket AM3+
ATXPWR 2
Note: represents the 1
st
pin.
