1.3 Motherboard Specifications
Specifications
CPU Support
Socket 1150 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Watt
* Please refer to
www.biostar.com.tw for CPU support list.
Chipset INTEL® B85
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
2 x DDR3 DIMM Memory Slot, Max. Supports up to 16 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to
www.biostar.com.tw for Memory support list.
Storage
INTEL® B85, Supports AHCI
4x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
LAN
Realtek RTL 8111G
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC892, 7.1 Channels, High Definition Audio
(2-channel output is from front audio header)
USB
4x USB 3.0 port (2 on rear I/Os and 2 via internal headers)
6x USB 2.0 port (2 on rear I/Os and 4 via internal headers)
Expansion Slots
TB85
5x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot (x16)
TB85-BTC
7x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Mouse
1x PS/2 Keyboard
1x DVI-D Port
1x VGA Port
2x USB 3.0 Port
2x USB 2.0 Port
1x LAN port
3x Audio Jack
Internal I/Os
4x SATA 6.0Gb/s Connector
2x SATA 3.0Gb/s Connector
1x USB 3.0 Header (each header supports 2 USB 3.0 ports)
2x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x 4-Pin Power Connector
1x 24-Pin Power Connector
2x Auxiliary Power Connector
1x CPU Fan Connector
2x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x Serial Port Header
1x S/PDIF out Connector
1x Consumer IR Header
Form Factor ATX Form Factor, 295 mm x 210 mm
OS Support
Windows 7/ 8/ 8.1
Biostar reserves the right to add or remove support for any OS with or without notice.
