920-5000-XT-QSG Rev B www.birdrf.com (866) 695-4569
Setting Up
1. Connect the sensor.
2. Turn on the DPM.
3. Zero the sensor (WPS and TPS only).
4. Turn on the RF source.
5. Take a reading.
Note:
The analog bar graph will respond immediately to changes in the
RF power. The major and minor displays will respond after a delay of 1 to
13 seconds, depending on the power level.
Shutting Down
Press and Hold the “OK” key for 2 seconds. This will put the unit into Sleep
mode. It will stop logging in this mode.
Press and hold the “OK” key until the “OK” key illuminates, approximately 8
seconds. This will shut the unit down completely.
