Specifications
11
InputVSWR,Max. 1.05:1upto1GHz
Directivity,Typical
1
30dB
RFConnectors QCType(N(F)normallysupplied)
InterfaceConnector DB‐9
PowerSupply Fromhostinstrumentviacable
MechanicalShockandVibration Inaccord ancewithMIL‐PRF‐28800FClass3
CE
CEcompliant.RefertoDOCforspecific
standards.
RecommendedCalibrationInterval 1year
Temp,Operating –10to+50°C(+14to+122°F)
Temp,Storage –40to+75°C
(–40to+167°F)
Humidity,Max 95%(non‐condensing)
Altitude,Max 3,000m(10,000ft.)
Dimensions,Nominal
5.0”x2.4”x2.0”
(130x60x50mm)
Weight,Nominal 0.9lb.(0.4kg)
1Exactvaluedependsonelementselected
2Above35°Corbelow15°Cadd2%
