BIRD 5009 - Connecting the Directional Power Sensor (DPS)

Installation
5
Connecting the Directional Power Sensor (DPS).
1. Dooneofthefollowing:
a. Toconnecta5009DPS:
Note: OnlyuseDPMelementsinthe5009DPS.
WARNING
NeverattempttoconnectordisconnectRFequipmentfromthetransmission
linewhileRFpowerisbeingapplied.
LeakingRFenergyisapotentialhealthhazard.
WARNING
RFvoltagemaybepresentinRFelementsocket.Keepelementinsocket
duringoperation.
