Spare Parts List
Model: 1002102
Tools:
i) Scraper - 1315138
ii) Allen Key - 1315048
NO DESCRIPTION QTY CODE
1 TOP COVER 1
2 MAIN HANDLE 1
3 ELEMENT FIXING PLATE (UPPER) 1 1315131
4 REAR SPRING COVER 1
5 ELEMENT (UPPER) 1 1315133
6 CAST PLATE (UPPER) 1
7 CAST PLATE (LOWER) 1
8 HINGE 1 1315136
9 PLATE CONNECTING SPRING 1
10 ELEMENT (LOWER) 1 1315137
11 ELEMENT FIXING PLATE (LOWER) 1
12 THERMAL CUT OUT DEVICE 1 1315121
13 MAIN BODY 1
14 LEAD + PLUG 1 1315011
15 CERAMIC TUBE 2
16 ADJUSTABLE BRACKET 1
17 BASE 1
18 FEET 4 1315125
19 THERMOSTAT 1 1315004
20 THERMOSTAT DIAL 1 1315007
21 INDICATOR LIGHT 1 1315005
22 ON/OFF SWITCH 1 1315112
23 DRIP TRAY 1
24 ELEMENT FIXING PLATE 1
25 SMALL HANDLE 1
26 INSULATION FIXING PLATE (UPPER) 1
27 ADJUSTABLE BRACKET SCREW 1
To Next Page
