Birko 1002101 - Explosion View and Spare Part List

7
Spare Parts List
Model: 1002101
Tools:
i) Scraper - 1315138
ii) Allen Key - 1315048
NO DESCRIPTION QTY CODE
1 TOP COVER 1
2 MAIN HANDLE 1 1315317
3 ELEMENT FIXING PLATE (UPPER) 1
4 REAR SPRING COVER 1
5 ELEMENT (UPPER) 1 1315318
6 CAST PLATE (UPPER) 1
7 CAST PLATE (LOWER) 1
8 HINGE 1
9 PLATE CONNECTING SPRING 1
10 ELEMENT (LOWER) 1 1315319
11 INSULATION FIXING PLATE (LOWER) 1
12 THERMAL CUT OUT DEVICE 1 1315121
13 MAIN BODY 1
14 LEAD + PLUG 1 1315011
15 CERAMIC TUBE 2
16 BASE PLATE 1
17 FEET 4 1315125
18 THERMOSTAT 1 1315004
19 THERMOSTAT DIAL 1 1315007
20 INDICATOR LIGHT 1 1315005
21 ON/OFF SWITCH 1 1315112
22 DRIP TRAY 1
23 ELEMENT FIXING PLATE (LOWER) 1
24 SMALL HANDLE 1 1315127
25 INSULATION FIXING PLATE (UPPER) 1
26 ADJUSTABLE BRACKET 1
