BIRO 22 - Toggle Switch Wiring Diagrams

21
TOGGLE SWITCH (6808-G/7810-G) WIRING DIAGRAMS
T3
T1
T4
T2
LINE 1 LINE 2
6808-G
TOGGLE
SWITCH
MOTOR JUNCTION BOX
T2
T1
T3
T4
LINE 1 LINE 2
6808-G
TOGGLE
SWITCH
MOTOR JUNCTION BOX
110-115 VOLTS 220-230 VOLTS
7810-G
TOGGLE
SWITCH
MOTOR JUNCTION BOX
3 PHASE/ 230 VOLTS
50/60 HZ ELECTRICAL
SUPPLY
L1 L2 L3
1 2 3
4 5 6
7 9
7810-G
TOGGLE
SWITCH
MOTOR JUNCTION BOX
3 PHASE/ 440 VOLTS
50/60 HZ ELECTRICAL
SUPPLY
4 5 6
7 8 9
8
L1 L2 L3
1 2 3
