– 208/220/440 WITH 3 PHASE MOTOR –
Model 3334 Schematic Using 3-Pole Stromberg or AEG W.T. Switch
for 208-220/440 Volts, Three Phase, 60 Cycle US or Baldor Motor
30
Item No. Description
AN15S Acorn nut,
1
4
-20, SS
FW05S Flat washer,
1
4
,SS
FW07S Flat washer,
3
8
,SS
FW08S Falt washer,
3
8
ID
´
1OD, SS
FW10S Flat washer,
5
16
,SS
FW15S Flat washer,
1
2
, SS
HHS003S Trimmed hex head screw,
8
32
´
1
4
,SS
HHS005S Hex head screw, 10-32
´
3
8
,SS
HHS010S Hex head screw,
8
32
´
1
2
, SS
HHS015S Hex head screw, 10-32
´
7
8
,SS
HHS020S Hex head screw,
1
4
-20
´
3
8
, SS
HHS025S Hex head screw,
1
4
-20
´
1
2
,SS
HHS035S Hex head screw,
1
4
-20
´
5
8
,SS
HHS040S Hex head screw,
1
4
-20
´
3
4
,SS
HHS049NL Hex head screw,
5
16
-18
´
1
2
, nylon
HHS050S Hex head screw,
5
16
-18
´
5
8
,SS
HHS055S Hex head screw,
5
16
-18
´
3
4
,SS
HHS060S Hex head screw,
5
16
-18
´
1, SS
HHS070S Hex head screw,
3
8
-16
´
1, SS
HHS075S Hex head screw,
3
8
-16
´
1
1
4
,SS
HN05S Hex nut, 8-32, SS
HN10S Hex nut, 10-32, SS
HN15S Hex nut,
1
4
-20, SS
HN20S Hex nut,
5
16
-18, SS
HN25 Hex nut,
3
8
´
16
HN25S Hex nut,
3
8
-16, SS
HN30S Hex nut,
3
8
-16, light jam, SS
HN35S Hex nut,
3
8
-16, SS
LH663 Left hand saw guard
LW05S Lock washer, #10, SS
LW10S Lock washer,
1
4
,SS
LW15S Lock washer,
5
16
,SS
LW20S Lock washer,
3
8
, regular, SS
LW25S Lock washer,
3
8
,SS
M55-G54313-U Motor, 2HP 208/220/440-50/60-3, open
M68-67385-D Motor, 2HP, 208/220/440-50/60-3, TE
M701-G57011-U Motor, 3HP, 208/220/230/440-50/60-3, TE
RHS20S Round head screw, 10-32
´
1
1
8
,SS
RHS10S Round head screw, 10-32
´
3
4
,SS
Item No. Description
RHS25S Round head screw,
1
4
-20
´
3
4
,SS
RHS30S Round head screw,
1
4
-20
´
7
8
,SS
S1007 Channel bracket, SS (3334-4003 only)
S11 Ratchet trigger
S1120EZ Channel, SS (3334-4003 only)
S12214 Platter bracket starting with S/N 24464*
S155-11 Meat carr stop thumb screw
S155B Meat carriage stop welded
S155EZ-3 Hex standoff, EZ flow carriage
S16005C Head, SS
S16006 Head door, SS
S16007 Channel bracket SS
S16015-1 Motor baseplate adjusting stud, SS
S16120 Channel stainless steel
S16217L Base door left panel SS, see page 23
S16217LTP Base door left tapered panel, SS, see page 23
S16217R Base door right hinged SS
S16239-5 Base, stainless steel
S16273 Meat gauge bracket SS
S16275 Meat gauge plate, SS
S16290 Cleaning unit stamping SS
S16296-8 Switch brkt Kroger 800S2SA4
S16335X Upper wheel hinge plate, SS
S181155AEZ Meat carriage angle, EZ flow (3334-4003 only)
S18155EZ-1 Carriage top w/weld studs (3334-4003 only)
S189 Ratchet arm stud, stainless
S19 Ratchet base, stainless
S200B1 Stopstud gde bar & crg stp SS
S217C Base door hinge pin long SS
S217E Base door hinge pin short SS
S229 Wheel cleaner arm torsion spring, SS
S235 Taper pin, stainless, 4
´
3
4
S239-B30 Base foot welded, SS
S239-B40 Base leg, welded
S239-B41 Hex leg, adjustable
S240 Ratchet trigger spring
S244 Wheel cleaner arm stud SS
S253 Upper wheel aligning screw, SS
S262 Meat gauge release handle
