24
HOIST HOUSING ASSEMBLY
Diagram A.
PARTS LIST
PART NO.
PART NAME
PART NO.
PART NAME
1.
HOIST NAME PLATE
25.
PULL ROTOR
2.
SOCKET SCREW
26.
THRUST DISC
3.
FLAT WASHER
27.
THRUST COLLAR
4.
HOIST ELECTRICAL GASKET
28.
BRAKE DRUM ASSEMBLY
5.
COVER HINGE RETAINING SCREW
29.
MOTOR COVER ASSEMBLY
6.
SPLIT WASHER
30.
SPLIT WASHER
7.
OIL DRAIN PLUG
31.
SOCKET SCREW
8.
RUBBER SEAL
32.
FAN
9.
GEAR BOX CASTING PT. 1
33.
SEAL
10.
GEAR BOX GASKET
34.
KEY
11.
GEAR BOX CASTING PT. 2
35.
FAN WASHER
12.
RUBBER SEAL
36.
SNAP RING
13.
OIL INSPECTION PLUG
37.
FAN COVER
14.
MOTOR GASKET
38.
SPLIT WASHER
15.
OIL FILL PLUG (A.)
39.
SOCKET SCREW
16.
SLOTTED PIN
40.
MOTOR FRAME WITH STATOR
17.
OIL FILL PLUG (B.)
41.
CONED DISC SPRING
18.
RUBBER SEAL
42.
BRAKE SPRING
19.
SLOTTED PIN
43.
CONED DISC SPRING
20.
SPLIT WASHER
44.
COLLAR
21.
SOCKET SCREW
45.
SPACER
22.
SLOTTED PIN
46.
LOCK WASHER
23.
SOCKET SCREW
47.
NUT
24.
MOTOR SHAFT WITH ROTOR
