TECHNICAL SPECIFICATIONS
DUAL SPEED HOIST
Product Code
Capacity
Standard
Lift Height
Push
Button
Cord
Lifting
Speed
Motor
Output
Control
Voltage
Lifting Motor Rated
Current (amps)
Load Chain
Size Ø
Chain
Fall
Lines
Net Weight
tons
feet
feet
ft/min
hp
Volts
@230v
@460v
mm
lbs.
HHBDSK01-01D
1
20
17
23.6 / 7.9
2.01
110
9/3.8
7/2.4
Ø 8 x 24
1
147.70
HHBDSK02-01D
2
20
17
14.4 / 4.6
2.01
110
7/4
4.5/2.6
Ø 10 x 30
1
196.20
HHBDSK03-01D
3
20
17
24 / 4.8
4.02
110
8.5/12
6.5/8.5
Ø 11.2 x 34
1
330.70
HHBDSK05-02D
5
20
17
7.2 / 2.3
4.02
110
8.5/12
6.5/8.5
Ø 11.2 x 34
2
412.30
Product Code
Capacity
Headroom (C)
A
B
D
E
K
L
N
tons
inches
inches
inches
inches
inches
inches
inches
inches
HHBDSK01-01D
1
20.15
23.54
12.6
11.81
8.31
1.57
1.26
0.94
HHBDSK02-01D
2
22.50
25.51
12.99
12.60
8.10
1.93
1.57
1.18
HHBDSK03-01D
3
30.95
31.02
15.55
18.31
12.75
2.32
1.77
1.38
HHBDSK05-02D
5
40.50
31.02
15.55
18.31
12.75
2.36
1.77
1.69
