MOTORIZED TROLLEY ASSEMBLY
Diagram E.
PARTS LIST
PART NO.
PART NAME
PART NO.
PART NAME
1.
SOCKET BOLT
25.
BALL BEARING
2.
SPRING WASHER
26.
CIRCLIP
3.
BRAKE CAP
27.
ELECTRICAL PLATE GASKET
4.
BALL BEARING
28.
ELECTRICAL PLATE COVER
5.
BRAKE ASSEMBLY
29.
SPRING WASHER
6.
SEAL
30.
SOCKET BOLT
7.
SOCKET BOLT
31.
TROLLEY MOTOR ASSEMBLY SIDE
PLATE
8.
SPRING WASHER
32.
GEAR SHAFT
9.
MOTOR COVER
33.
GEAR
10.
MOTOR STATOR
34.
SELF-LOCKING NUT
11.
BRAKE SPRING
35.
COLLAR/ SPACER
12.
ROTOR ASSEMBLY
36.
SPLIT PIN
13.
BALL BEARING
37.
TROLLEY SHAFT
14.
MOTOR COVER PLATE
38.
SOCKET BOLT
15.
MOTOR PLATE GASKET
39.
SPRING WASHER
16.
CIRCLIP
40.
ROLLER SHAFT
17.
GEAR
41.
ROLLER WHEEL BRACKET
18.
SOCKET BOLT
42.
TROLLEY ELECTRICAL SIDE PLATE
19.
SPRING WASHER
43.
GASKET
20.
GEAR BOX
44.
ELECTRICAL CONTROL CASE
21.
SPRING WASHER
45.
SPRING WASHER
22.
SOCKET BOLT
46.
SOCKET BOLT
23.
SOCKET BOLT
47.
ELECTRIC CONTROL CASE
24.
CIRCLIP
48.
HEAD SCREWS
