Mainnce & Care
Machine storage
For best results, a few simple steps can assure
your machine is well maintained after your
cleaning is complete.
1. Wrap power cord around Quick Release
Cord Wrap™ on side of the machine.
2. Wipe all surfaces with a soft cloth. Store
machine upright in a protected, dry area.
NOTE: You may have cleaning formula
remaining in the solution tank. You may store
your machine this way for the next cleaning
task, but never keep dirty water in the
collection tank.
Install the replacement brush belt
1. Turn the machine off and unplug from
wall outlet.
2. Remove solution and collection tanks.
3. Lay machine down to access the bottom
of the machine.
4. With a Phillips head screwdriver, unscrew
the belt cover and remove.
5. Remove the brush end cap and remove
belt from brush.
6. Brush can now be removed.
7. Belt can be removed by sliding off the
motor pulley.
8. Clean or replace belt. Attach belt to
motor pulley and brush, insert brush into
right side end cap.
9. Reattach the left end cap and slide brush
back into place.
10. Replace the belt cover and screw into place.
11. Manually rotate brush to make sure it rotates
freely and that the belt is aligned properly.
WARNING
To reduce the risk of electric shock, turn power switch
o and disconnect plug from electrical outlet before
performing maintenance or troubleshooting checks.
CAUTION
Do not store unit where freezing may occur.
Damage to internal components may result.
4.
5.
10.
