Basic Installation
How to remove the left side panel
Front Top Back Side
Remove both thumb screws Slide the side panels towards
the back of the case
4. Graphics Cards support
max Up to 339mm
5. Acrylic see-through top cover
1. Magnetic filter on top
3. High flow filter front panel
6. UP TO 280mm Radiator bracket on top
2. New Enhanced Edition Handle
BitFenix FyberFlex™ Composite Handles
7. Removable SDD/HDD 5 bracket
11. Magnetic filter on bottom
12. Pre-installed 60mm fan
13. Pre-installed 120mm fan
9. Vertical graphics card bracket
8. 120 mm water cooling bracket
10. Tempered glass
04
