BIXOLON BCD-1000 User Manual

Rev. 1.00
- 4 -
BCD-3000
1. Product Components
• The following display models are available
BCD-3000
No Component Description
1
Brightness Level
Control Switch (knob)
Control the brightness level of the backlight on the display
2 Display
Features a LCD screen.
The screen can be tilted.
Remove the protective film on the screen before use.
3
Stand
Support the display and must be placed on a flat surface.
4
USB Cable
Used to connect to a PC.
5
Serial Cable (RJ45)
Used to connect to the printer.
1
2
3
4
5
