BIXOLON BCD-3000 - VMSM (Virtual Memory Switch Manager)

Rev. 1.00
- 11 -
BCD-3000
6 VMSM (Virtual Memory Switch Manager)
• Other than DIP switch settings, you can change the following settings using VMSM software.
The following settings apply when powered on and are executed by the initialization
command.
1) MSW 1
Memory
S/W
Function Default Content to be set Range to be set
1
Character code table
Selection
n=0 Page 0 is selected
0,17,18,20,27,31
or
0,1,2,3,4,5,14,15,16,
17,18,19,20,21,25,
26,27,28,29,30,31,32,
33,36,38,40,41,49,50,51
2
International character
set selection
n=0 U.S.A is selected 0-15
3
Selection of the
peripheral devices
n=2 Display is selected 1-3
4
Cursor display
n=1
Cursor On
0, 1
5 ~ 8
Reserved
-
-
2) MSW 2
Memory
S/W
Function Default Content to be set Range to be set
1 ~8
Reserved
-
-
-
