BIXOLON SPP-R200 - Leather Case (Optional) Usage

Rev. 1.09
- 18 -
SPP-R200
3-5 Leather Case (Optional) Usage
1) Undo the Velcro.
2) Place the printer into the leather case
following the direction shown in the
image.
3) Close the Velcro.
4) Affix to a belt using the clip at the rear of
the case.
NOTE
The clip on the leather case can be rotated two
stages by 30° per stage (maximum 60°)
Belt
