BIXOLON SPP-R200II User Manual

Rev. 1.02
- 13 -
SPP-R200II
3-2-2 Using Single Battery Cradle (Optional)
1) Connect the power cord ② to the
battery charger ①.
2) Connect the battery charger ① to the
power connector of the single battery
cradle ③.
3) Plug the power cord ② into an electrical
outlet.
4) Insert the battery ④ into the single
battery cradle ③ until a snapping sound
is heard.
3-2-3 Using Vehicle Charger (Optional)
1) Turn off the power to the printer.
2) Connect the vehicle charger ① to your
car’s cigarette lighter jack.
3) Open the external interface protection
cap in the direction of ②.
4) Connect the vehicle charger to the power
connector.
CAUTION
The printer may be seriously damaged if a
battery charger not provided by BIXOLON is
used. BIXOLON is not liable for such damage.
WARNING
Turn off the power before charging the battery
for the printer.
①
②
①
②
③
④
①
③

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
