SPP-R300
3-2-3-2 Battery Charging
1) Insert the battery into the Quad
charger as shown in the figure on the
left.
2) Gently slide the battery until it
reaches the bottom of the charger.
3) Charging starts as soon as the
battery is completely inserted.
4) After charging, remove the battery
from the Quad charger.
NOTE
Battery charging status descriptions are as follows.
Lamp Charge Status Charge Time
Red Lamp On Charging
Green Lamp On Fully Charged
Red Lamp Blinking
Battery Defective or Poor
Installation
Within four hours
CAUTION
1. If the red lamp of the charger blinks, install the battery again.
2. If the red lamp continues to blink despite several attempts (4 ~ 5 times) to
install the battery, contact your local dealer.
3. The charging time may vary depending on the type of the charger or ambient temperature.
