BIXOLON SRP-332II Command Manual

SRP-330II/332II
Rev. 1.00 BIXOLON
- 106 -
GS ^
Function:
Execute macro
Code:
ASCII
GS
^
r
t
m
Hex
1D
5E
r
t
m
Decimal
29
94
r
t
m
Range:
0 ≤ r ≤ 255
0 ≤ t ≤ 255
m=0, 1
Default:
None
Description:
■ This command executes a macro using parameters as following:
• r specifies the number of times to execute the macro.
• t specifies the waiting time before the macro is executed.
• m specifies macro executing mode as shown below.
m
Function
0
Executes the macro r times continuously at the interval specified by t.
1
The printer waits for the paper FEED button to be pressed for the time specified by t. The macro is
executed once when the button is pressed. This operation is repeated r times.
Remarks:
■ The macro is defined by GS:
■ If the macro is not defined or r = 0, the command is ignored.
■ The macro function is useful to print the same data repeatedly.
Differences:
None
