BIXOLON SRP-332II Command Manual

SRP-330II/332II
Rev. 1.00 BIXOLON
- 118 -
GS w
Function:
Set bar code width
Code:
ASCII
GS
w
n
Hex
1D
77
n
Decimal
29
119
n
Range:
2 ≤ n ≤ 6
Default:
n = 3
Description:
■ This command sets the horizontal size of the bar code, using n as follows:
n
Multi-level bar code module
width (mm)
Binary-level bar code
Thin element width (mm)
Thick element width (mm)
2
0.282
0.282
0.706
3
0.423
0.423
1.129
4
0.564
0.564
1.411
5
0.706
0.706
1.834
6
0.847
0.847
2.258
• n specifies the bar code module width.
Remarks:
■ The setting of this command is effective for the following bar codes:
• Multi-level bar codes (UPC-A, UPC-E, JAN13, HAN8, CODE93, CODE128)
• Binary-level bar codes (CODE39, ITF, CODABAR)
■ The setting of this command remains effective until ESC @, printer reset or power cycling is executed.
