BIXOLON SRP-332II Command Manual

SRP-330II/332II
Rev. 1.00 BIXOLON
- 59 -
GS ( L, GS 8 L
Function:
Select graphics data
Code:
ASCII
GS
(
L
pL
pH
m
fn
[parameter]
Hex
1D
28
4C
pL
pH
m
fn
[parameter]
Decimal
29
40
76
pL
pH
m
fn
[parameter]
ASCII
GS
8
L
p1
p2
p3
p4
m
fn
[parameter]
Hex
1D
38
4C
p1
p2
p3
p4
m
fn
[parameter]
Decimal
29
56
76
p1
p2
p3
p4
m
fn
[parameter]
Range:
None
Default:
None
Description:
This command processes graphics data according to the function code (fn).
fn
No.
Format
Function
0, 48
48
GS ( L pL pH m fn
Transmits the NV graphics momory capacity
2, 50
50
GS ( L pL pH m fn
Prints the graphics data in the print buffer
3, 51
51
GS ( L pL pH m fn
Transmits the remaining capacity of the NV grapics memory
64
64
GS ( L pL pH m fn d1 d2
Transmits the defined NV graphics key code list
65
65
GS ( L pL pH m fn d1 d2 d3
Deletes all NV graphics data
66
66
GS ( L pL pH m fn kc1 kc2
Deletes the specified NV graphics data
67
67
GS ( L pL pH m fn a kc1 kc2 b xL xH
yL yH [c d1…dk]1…[c d1…dk]b
Defines the graphics data in the non-volatile memory
69
69
GS ( L pL pH m fn kc1 kc2 x y
Prints the specified NV graphics data
112
112
GS ( L pL pH m fn a bx by c xL xH yL
yH d1…dk
Stores the graphics data in the print buffer memory
