BIXOLON SRP-350III Command Manual

SRP-350/352III
Rev. 1.00 BIXOLON
- 5 -
No.
Command
Function
51
GS H
Select print position of HRI characters
52
GS I
Transmit printer ID
53
GS L
Set left margin
54
GS V
Select cut mode and executes a partial cut
55
GS W
Set print area width
56
GS ^
Execute macro
57
GS a
Enable/Disable Automatic Status Back (ASB)
58
GS f
Select font for HRI characters
59
GS h
Set bar code height
60
GS k
Print bar code
61
GS r
Transmit status
62
GS v 0
Print raster bit image
63
GS w
Set bar code width
64
BS M
Select device font type
65
BS V
Select cut mode and executes a partial/full
cut
66
BS ^ P
Set power saving mode

BIXOLON SRP-350III Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
USB port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Parallel ports quantity	1
Mean cycles between failures (MCBF)	70000000
Flash memory	32 MB
Certification	EnergyStar
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, PDF417, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Built-in sensors details	Paper End, Paper Near End, Cover Open
Product color	Black
Media thickness	0.062 - 0.075 mm
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
Weight	1550 g
