BIXOLON SRP-350V Command Manual

Thermal POS Printer
Ver. 1.00 BIXOLON
- 26 -
ESC 3
Function:
Set line spacing
Code:
ASCII
ESC
3
n
Hex
1B
33
n
Decimal
27
51
n
Range:
0 ≤ n ≤ 255
Default:
Corresponding to the default line spacing defined by ESC 2
Description:
■ This command sets the line spacing using a following rule.
• Line spacing = n x (vertical or horizontal motion units)
Remarks:
■ With standard mode selected, the vertical motion unit is used.
■ In page mode, the horizontal motion unit is applied when printing start poison is defined to the upper right or lower
right of print area using ESC T, otherwise, the vertical motion unit is used.
■ The line spacing is settable independently for each of standard and page modes.
Differences:
Vertical or horizontal motion unit and maximum line spacing settable:
Model
Vertical unit
Horizontal unit
Max line spacing
180dpi
0.0705mm (1/360 inch)
0.141mm (1/180 inch)
17.98mm
203dpi
0.0625mm (1/406 inches)
0.125mm (1/203 inches)
15.937mm
