SRP-E300/302
Ver. 1.01 BIXOLON
- 115 -
GS r
Function:
Transmit status
Code:
ASCII
GS
r
n
Hex
1D
72
n
Decimal
29
114
n
Range:
n = 1, 2, 49, 50
Default:
None
Description:
The command transmits the status specified by n as follows:
n
Function
1, 49
Transmits paper sensor status
2, 50
Transmits drawer kick-out connector status
Remarks:
■ The status is one byte.
■ The status to be transmitted is as follows:
• Paper sensor status (n=1, 49):
Bit
Off/On
Hex
Decimal
Function
0
Off
00
0
Reserved
1
Off
00
0
Reserved
2, 3
Off
00
0
Paper end sensor: Paper present
On
0C
12
Paper end sensor: Paper not present
4
Off
00
0
Fixed
5
Off
00
0
Reserved
6
Off
00
0
Reserved
7
Off
00
0
Fixed
Bits 2 and 3: This command can not be executed when the printer is offline due to the lack of paper. Therefore, the
status of bit 2 (1) and bit 3 (1) is not transmitted.
