BIXOLON SRP-E302 - Page 26

SRP-E300/302
Ver. 1.01 BIXOLON
- 26 -
ESC =
Function:
Select peripheral device
Code:
ASCII
ESC
=
n
Hex
1B
3D
n
Decimal
27
61
n
Range:
1 ≤ n ≤ 3, n = 16, n = 32, n = 48
Default:
None
Description:
This command selects the device to which the host computer communicates according to n as follows:
n
Function
1
Enables the printer
2
Disables the printer
3
Enables the printer
n
Function
16
Enables the printer, Disables the LCD
32
Disables the printer, Enables the LCD
48
Enables the printer, Disables the LCD
Remarks:
■ The printer discards all of the received data commands with the exception of ESC = and real-time commands while
being disabled.
■ The normal operation will be resumed by ESC @, power cycling or printer reset.
■ If LSB is activated when the printer is disabled by this command, the status is transmitted to the host at a preset
interval.
Differences:
None
