BIXOLON SRP-E302 Command Manual

SRP-E300/302
Ver. 1.01 BIXOLON
- 61 -
<Function 48> GS ( L pL pH m fn (fn=0, 48)
Code:
ASCII
GS
(
L
pL
pH
m
fn
Hex
1D
28
4C
pL
pH
m
fn
Decimal
29
40
76
pL
pH
m
fn
Range:
(pL + pH x 256) = 1 (pL=2, pH=0)
m=48
fn=0, 48
Default:
None
Description:
Tramsmits the total capacityu of the NV bit-image momory (number of bytes in the memory area).
Remarks:
Hexadecimal
Decimal
Amount of Data
Header
37H
55
1 byte
Identifier
21H
33
1 byte
Setting value
30H or 31H
48 or 49
8 bytes
NUL
00H
0
1 byte
■ The total capacity data is converted to character codes corresponding to decial data, then transmitted from the MSB.
■ The data length is variable.
■ The total capacitu of the NV user memory is selectable as any one of[0, 64K, 128K, 192K, 256K] bytes with GS ( E.
The default value is 256K.
Differences:
None
