SRP-E300/302
Ver. 1.01 BIXOLON
- 80 -
<Function 069> GS ( k pL pH cn fn m n (fn=69)
Code:
ASCII
GS
(
k
pL
pH
cn
fn
m
n
Hex
1D
28
6B
04
00
30
45
m
n
Decimal
29
40
107
4
0
48
69
m
n
Range:
(pL + pH x 256) = 4 (pL=4, pH=0)
cn=48
fn=69
m=48
48 ≤ n ≤ 56
Default:
None
Description:
■ This command specifies the error correction level for PDF417.
• The error correction level is set by “level”.
Remarks:
■ Settings of this function affect the processing of Functions 081.
■ Error correction level specified by “level” (m=48) is as follows:
The number of the error correction codeword is unchanged regardless of the number of codeword in the data area.
n
Function
Number of error correction codeword
48
Error correction level 0
2
49
Error correction level 1
4
50
Error correction level 2
8
51
Error correction level 3
16
52
Error correction level 4
32
53
Error correction level 5
64
54
Error correction level 6
128
55
Error correction level 7
256
56
Error correction level 8
512
■ The setting of this command remains effective until ESC @, printer reset or power cycling is executed.
Differences:
None
