SRP-E300/302
Ver. 1.01 BIXOLON
- 93 -
<Function 580> GS ( k pL pH cn fn m d1...dk (fn=80)
Code:
ASCII
GS
(
k
pL
pH
cn
fn
m
d1...dk
Hex
1D
28
6B
pL
pH
3D
50
30
d1...dk
Decimal
29
40
107
pL
pH
61
80
48
d1...dk
Range:
0 ≤ (pL + pH x 256) ≤ 3116 (0≤ pL ≤255, 0 ≤ pH ≤13)
cn=61
fn=80
m=48
0 ≤ d ≤ 255
k = (pL + pH x 256) – 3
Default:
None
Description:
This command stores DATAMATRIX symbol data in the symbol storage area.
Remarks:
■ The data stored to the symbol storage area by this command is executed by Function 581. The data remains
reserved in the symbol storage area.
■ The setting of this command remains effective until the following processing is performed:
• Performing Function 580
• Performing ESC @
• Performing the printer reset or power-off
Differences:
None
