BIXOLON SRP-F310II Command Manual

SRP-F310/F312/F313II
ESC S
Function :
Select standard mode
Code :
ASCII
ESC
S
Hex
1B
53
Decimal
27
83
Range :
None
Default :
None
Description :
This command enables standard mode.
Remarks :
■
The data in the printer buffer is cleared and the setting by ESC W returns to the default.
■ The conditions by the following commands are defined independently in standard mode and page mode.
• ESC SP, ESC 2, and ESC 3
■
In standard mode, CAN and GS $ are ignored.
Differences :
None
Rev. 1.00 BIXOLON
- 37 -

BIXOLON SRP-F310II Specifications

General

Print Method	Direct Thermal
Print Width	Up to 72 mm
Paper Thickness	0.06 ~ 0.08 mm
Weight	1.5 kg
Paper Loading	Easy Paper Loading
NV Image	Yes
Resolution	203 dpi
Interface	USB, Serial, Ethernet, Bluetooth
Paper Width	80 mm
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0 ~ 45 °C
Storage Temperature	-20 ~ 60 °C
Humidity	10% to 80% RH (non-condensing)
Emulation	ESC/POS
Receive Buffer	4 KB
