90.011
VS 12 / VS 12 W
080.98.3.1001
14
E
Textpage
Lang.
Spare parts list No. Device series (code No.)
Bitte unbedingt 11 stellige BESTELL--Nr. angeben
Please always indicate 11 digit Order No.
Absolument nécessaire d’indiquer No. de commande (11 chiffres)
Favorisca specificarci sempre il N. di ordine a11cifre
Es imprescindible que citen el ”No. de pedido (11 guarismos)
Amendment 04/2000
No. in drawing
X
From
status..
onwards
X
Designation
X
Pcs.
X
Order No.
X
21--100--5 60270201802 001 WASHER WITH BOLT 000
21--100--7 60800201500 001 LOCK WASHER 000
21--100--9 60270202300 001 WASHER 000
21--100--11 60800202001 001 SHAFT 000
60800202002 001 SHAFT 000
21--100--12 96055070000 000 LUBRICATING GREASE PARALIQ GA 343 000
21--100--13 95972840000 000 SCREW SEALING ADHESIVE 50ML LOCTITE 648 000
21--100--14 60800201900 001 LEVER EXTENSION 000
21--100--15 00110500002 003 WASHER 6.2 000
21--100--17 60270202800 003 WASHER 000
21--100--19 50001670000 001 CUP SPRING 18.8X10.2X0.25 000
56755650000 001 WASHER 6.4 000
21--100--21 57431100000 001 HEXAGON SCREW M 6X10 000
21--100--22 95972950000 000 SCREW SEALING ADHESIVE 50ML LOCTITE 243 000
21--100--23 60350402001 001 PROTECTIVE PLUG 16.2 KNURLED 000
21--100--30 56046530000 001 THREADED PIN M 10X35 000
21--100--31 60370203400 001 SEALING 000
21--100--32 56086100000 001 CYLINDRICAL HANDLE GN519 28 M10 000
21--100--33 95972950000 000 SCREW SEALING ADHESIVE 50ML LOCTITE 243 000
21--100--34 95972840000 000 SCREW SEALING ADHESIVE 50ML LOCTITE 648 000
21--145 60370401900 002 SCREW 000
21--150 60800302100 001 REAR WALL, NARROW 000
21--151 60800302200 001 ADHESIVE FOIL 000
21--152 56739050000 002 WASHER A 5.3 000
21--153 57767050000 002 SPRING WASHER A 5 000
21--154 56444500000 002 HEXAGON NUT FLAT--TYPE BM 5 000
21--155 60370402200 002 PROTECTIVE PLUG 000
21--160 60800300401 001 SUPPORTING PLATE 000
21--165 60800305301 001 TRUNNION 000
21--174 95972840000 000 SCREW SEALING ADHESIVE 50ML LOCTITE 648 000
21--175 56359300000 001 PARALLEL NOTCHED PIN 3 X12 000
21--180 60800204002 001 REMNANT HOLDER COMPL. 000
21--210 60800305001 001 BIAS CUT PLATE COMPL. 000
21--210--1 60800305101 001 BIAS CUT PLATE 000
21--210--2 60800305200 001 LOCKING BOLT 000
