18
Figure 9. Connecting Two Power Supplies in Parallel.
OPERATING INSTRUCTIONS
Output current
equals sum
of both ammeter
Load
Power supplies
to same voltage
Use load equalizing
resisters
0.1
1W
0.1
1W
