6
SPECIFICATIONS
Model 1730A Model 1710A
OUTPUT VOLTAGE 0 to 30 VDC, coarse and fine adjustment 0 to 30 VDC, coarse and fine adjustment
OUTPUT CURRENT
High Range
Low Range
0 to 3A
0 to 0.5A
0 to 1A
0 to 0.25A
CONSTANT VOLTAGE OPERATION
Voltage Regulation
Line (108 - 132V)
Load (no load to full load)
Recovery Time
Ripple Voltage
Peak-to-Peak
RMS
Temperature Coefficient
0° to +40° C
0.01% + 3mV
0.01% + 3mV
100µs typical
2mV typical
1mV
300 PPM/°C
0.01% + 3 mV
0.01% + 3 mV
100µs typical
3mV typical
1mV
300 PPM/°C
CONSTANT CURRENT OPERATION
Adjustable Current Limits
Current Regulation
Line (108 - 132V)
Load
Current Ripple
5 to 100%
0.2% + 3mA
0.2% + 3mA
3mA typical
5 to 100%
0.2% + 3mA
0.2% + 3mA
3mA typical
